Compressor Room Layout: Air Receiver Sizing and Placement, Continued

Hybrid Systems

We left our discussion determining that an air receiver for a load/unload rotary screw compressor system is best sized around 5-gal/cfm. Still staying in the compressor room for now, let’s discuss how many air receivers are necessary and where to locate them.

Once again there is no clear right or wrong way of doing things. Some will recommend a single “wet” receiver and others will insist all receivers be placed on the “dry” side of air treatment. Both scenarios have advantages and disadvantages.

Let’s review each and maybe interject a hybrid solution.


“Wet” Air Receiver

Advantages:

  • Provides excellent moisture separation
  • Allows cooling of compressed air
Disadvantages:

  • Potentially can over flow air treatment
  • Internal corrosion
  • Allows for proper operation of capacity control

“Dry” Air Receiver

Advantages:

  • Air treatment protection
  • Minimal internal corrosion
  • Supply of dry compressed air for large intermittent demands

Disadvantages:

  • Potential slugging air treatment with large quantities of liquids
  • Potential high inlet temperatures to air treatment
  • Pressure drop between tank and compressor capacity system

I am certain there are more than the ones I’ve mentioned.


If you have to choose…

In my opinion, if you only have room and money for one (1) tank,  make it a “wet” tank with a good, reliable zero loss drain.

Another option is the hybrid solution, which uses more than one (1) air receiver.


The Hybrid Solution

This solution is gaining in popularity as knowledge of the efficiency advantages are becoming more commonplace. Installing both a “wet” and “dry” air receiver provides the best solution with only minimal disadvantages. You still size the system for a total of 5-gallons/cfm of the largest cycling rotary screw compressor. But now you split the air receiver sizing so 1/3 of the capacity is on the “wet” side and 2/3 is on the dry side.

The pictures below show a recent installation for one of our customers:

This particular customer already had multiple tanks – so we re-worked the system so they had a single “wet” receiver and three (3) “dry receivers.

Wet tankDry tanks

Every application is different, you need a qualified, experienced professional to review all the parameters of the system and recommend the best solution.
